P6471X - CLAYTON SC-6 AIR BRAKE COMPRESSOR – REMANUFACTURED
PART NUMBER(S):
Fleet Products: P6471X (Remanufactured) | Replaces OE: Clayton: P6471 | CAT: 1W6592, 1W6753, 1W6754, 1W6755, 1W6756, 1P0028, POGA10593X, POGA713, 2P8709, 2P8710, 2P8711, 2P9614, 2P9613, 2P7794, 2P7795, 7N7764, 7N7770
DESCRIPTION:
Model: Clayton SC-6 Air Brake Compressor
Vehicles: Heavy trucks, semi trucks, 18 wheelers, and commercial truck applications
• Application: Air brake compressor for actuation of air brakes
• Air Inlet/Outlet Port Size: 3/8"-18 NPT
• Head Configuration: Water cooled or air cooled, varies by component
• Cooling: Water cooled
• Oil Pump Stroke: 6.35 mm / 0.25 in
• Oil Pump Relief Pressure: 0.7–1.0 kg/cm² at 500 RPM
• Reservoir Volume: 40 litres
• Oil Level: Indicator dipstick incorporated
• Function: Pressurizes air for air brake actuation
Applications:
Used on heavy truck and commercial vehicle air brake systems requiring a Clayton SC-6 compressor with 3/8"-18 NPT air inlet/outlet configuration. The compressor supplies pressurized air for service brake actuation and should be matched by cooling configuration, port size, oil pump setup, and application requirements before installation.
CROSS-REFERENCE(S):
No additional cross-reference numbers supplied.
A cross-reference listing means this part may be a suitable replacement for the listed part numbers. Always verify fitment before installation.
IMPORTANT INSTALLATION NOTES:
✔ Verify Clayton SC-6 configuration, air inlet/outlet port size, and cooling setup before installation
✔ Confirm oil pump relief pressure is set between 0.7–1.0 kg/cm² at 500 RPM
✔ Fill oil according to the incorporated indicator dipstick
✔ Confirm reservoir volume and compressor configuration match the original application
✔ Check air lines, oil system, and cooling configuration before startup
SOLD AS REMANUFACTURED | CORE RETURN REQUIRED
Built to OEM standards | thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
