Description
N16020X EL1600 PULLEY DRIVE COMPRESSOR
PART NUMBER(S):
Fleet Products: KN16020X (Remanufactured) | Replaces OE: Haldex: KN16020, EL16020, N7202 | Volvo: 42-1168, 70001-3802 | Detroit Diesel: 23500558
DESCRIPTION:
Model: EL1600 Pulley Drive Compressor
Vehicles: Heavy trucks, semi trucks, 18 wheelers, commercial trucks
• Mounting: 4-hole base mount
• Drive type: Belt driven / pulley drive
• Head rotation: Right
• Block rotation: Right
• Discharge type: Top / flange
• Cooling: Water cooled
• Bore x stroke: 2.75 in x 1.87 in
• External shaft length: 2.14 in.
• Cylinders: 2
• Rated displacement: 16.1 CFM at 1250 RPM
• Maximum turbo pressure: 35 PSI
• Identification: Distinctive tab on block
• Discharge note: Front-threaded, top flange
Applications: Used to pressurize air for air brake actuation in heavy-duty trucks, semi trucks, 18 wheelers, and commercial vehicles. This EL1600 pulley drive compressor uses a 4-hole base mount, belt-driven configuration, water cooling, and right-hand head and block rotation. Verify pulley drive, base mount, discharge orientation, and shaft length before installation.
CROSS-REFERENCE(S):
KN16020, EL16020, EL16060XBXR, BENEL16060X, BXEL16060X, 23500558, 2073575, 700010042, 700013802, KN16020N, KNT16020, KNX16020, EL16020X, ZZEL16020, ZZEL16020X, EMDEL16020X, N7202, N7202C, N7202D, N7202H, NT7202G, NT7202J, MBIEL16020X, MIDEL16020X, R955EL16020X, 42-1168, 70001-3802, E-MDEL16020X, P0370300, 33060007, 70001-0042, 421168
A cross-reference listing means this part may be a suitable replacement for the listed part numbers. Always verify fitment before installation.
IMPORTANT INSTALLATION NOTES:
✔ Verify 4-hole base mount and pulley drive configuration before installation
✔ Confirm right-hand head and block rotation before installation
✔ Confirm front-threaded / top flange discharge configuration before installation
✔ Use supplied installation gaskets and verify sealing surfaces before startup
SOLD AS REMANUFACTURED | CORE RETURN REQUIRED
Built to OEM standards | thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
