KB791054X - HT/S ADVANTAGE FAN CLUTCH (CUMMINS N14)
PART NUMBER(S):
Fleet Products: KB791054X (Remanufactured) | OE: 2022814C91, 91054, 981097, 981225, 991106, 991228
DESCRIPTION:
Model: HT/S Advantage
Vehicles: International 8000, 2000, 5000 Series (1994)
• Engine: Cummins N14
• Clutch Type: On/Off
• Belt Count: 2
• Belt Groove Type: V (2V)
• Belt Groove Location: 3.35"
• Fan Pilot Diameter: 5.00"
• Fan Blade Bolt Circle: 6"
• Pulley Diameter: 7.03"
• Vertical Mounting Distance: 5.25"
• Overall Length: 7.27"
• Friction Plate: 9.5"
Applications:
Is this fan clutch compatible with your Cummins N14-powered International✔ Yes—engineered for models like the 8000, 2000, and 5000 Series (1994), this HT/S Advantage delivers reliable on/off engagement and OEM fitment for sustained cooling performance in demanding fleet operations.
CROSS-REFERENCE(S):
2022814C91, 91054, 981097, 981162, 981225, 991106, 991166, 991228, KMN2091054, KM N20 91054, ABPN2091054, ABP N20 91054, FLT91054, KMI91054, 3443-91054, 1000-791054, 1000791054, 3912-791054, 3912791054, 791054-HO, 791054HO, ABP N20 91054, FC791054, HOR 791054, HOR-791054, HOR791054, HT791054, K791054, KM N20 91054, RC 791054, RC791054, ZBH791054A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Ensure belt groove location (3.35") aligns with existing pulley setup.
✔ Confirm 5.00" fan pilot matches your fan blade hub.
✔ Verify both vertical mounting distance (5.25") and bolt circle (6") before installation.
✔ Always torque fan blade bolts to manufacturer specifications for safe operation.
HTS Advantage Repair Kits:
SOLD AS REMANUFACTURED | CORE RETURN REQUIRED
Built to OEM standards | thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
WHY CHOOSE FLEET PRODUCTS | KBR - HEAVY DUTY TRUCK & TRAILER PARTS?
• Canadian-owned since 1985• Trusted by fleets, mechanics, and B2B partners across North America
• Fast, Reliable Shipping Across North America
• Competitive pricing with Core Return Refunds
• Price Match Guarantee | Find a better price? We'll beat the difference by 10%!
