Description
950068-G3 - MODEL IS COALESCING DESICCANT CARTRIDGE
PART NUMBER(S):
Fleet Products: 950068-G3 (New) | Replaces OE: Meritor R950068, R950068P, R950068PG | Wabco 4329012232, 4329012222, 4329012282, 4329012452, 4329012462, 4324102442, S4329012232 | Freightliner TDAR950068 | Volvo 20557234, 20754416, 20972915, 21620181, 85110799 | Baldwin BA5379, BA5592 | Donaldson P951413 | Torque TR950068
DESCRIPTION:
Model: Model IS / Model SP / System Saver coalescing desiccant cartridge
Vehicles: Freightliner M2 106, CL120, FLD120; Volvo VNL, VNM, VHD; Kenworth T2000, T600, T660, T800; Peterbilt 387, 389, 579
• Cartridge Type: Coalescing desiccant cartridge
• Function: Removes oil aerosols, moisture and contaminants from compressed air
• Dimensions: 6.00" height x 7.00" length x 6.00" width
• Thread Size: M39 x 1.5-6H RH
• Mounting Style: Spin-on direct replacement
• Service Note: 950068A / 4329012482-G3 uses SG39 x 1.5 mm thread
• Includes: O-ring and grease tube
• Installation Torque: 44.25 lb-in / 5 Nm
• Compatible Dryer Families: Model IS, Model SP, System Saver and SS1200 PG air dryers
Applications:
Designed for Model IS, Model SP, System Saver and SS1200 PG air dryers requiring coalescing filtration. This cartridge removes oil aerosols and moisture from compressed air to help protect valves, reservoirs, purge systems and downstream air brake components. Confirm M39 x 1.5 thread before installation; do not confuse with the SG39-thread 950068A / 4329012482-G3 cartridge.
CROSS-REFERENCE(S):
950068-G3, 950068, R950068, ETP-950068, R950068P, R950068PG, 109994PG, 2191P951413, 31005609, AD27747, AD27747FLG, R955099P, 4324102442, 4329012222, 4329012232, 4329012282, 4329012452, 4329012462, S4329012232, P951413, P953571, 20557234, 20754416, 20972915, 21620181, 3090268, 3090288, 745109994, 0004295695, AC1001C, LFP8845, S-27091, FR-BRKE007, BA5379, BA5592, TDAR950068, TR950068, 85110799
A cross-reference listing means this part should be a suitable replacement for the part numbers listed. Please confirm cartridge thread, dryer model and dimensions before installation.
IMPORTANT INSTALLATION NOTES:
✔ Use only with coalescing-type air dryers, including PG-style systems.
✔ Fully depressurize the air system before removing the cartridge.
✔ Verify M39 x 1.5-6H RH thread before installation.
✔ Replace the O-ring and apply supplied grease during installation.
✔ Torque to 44.25 lb-in / 5 Nm. Do not overtighten.
✔ Clean the housing seat before installing the new cartridge.
✔ After installation, inspect for leaks and verify proper air dryer purge operation.
