619111 - T-2000 HEATER KIT - 24V, 75W
PART NUMBER(S):
Fleet Products: 619111 (New) | Replaces OE: SKF / Haldex 619111 | Automann 170.SKF619111
DESCRIPTION:
Model: T-2000 / HD-2000 Series heater kit
Vehicles: Trucks, trailers, buses, military platforms including M939, LMTV / FMTV, and heavy-duty applications using compatible Turbo-2000 / HD-2000 air dryer systems
• Voltage: 24V DC
• Power: 75W
• Current Draw: 3.2 amps
• Thermostat Activation: 35°F
• Thermostat Deactivation: 55°F
• Plug Style: Grey heater plug with Metri-Pak connector
• Application: Turbo-2000 and HD-2000 air dryers
• Kit Includes: Heater element, thermostat and plug-style harness
• Installation Style: Two 8-32 x 1/2" screw mount
• Function: Helps prevent air dryer freeze-up during cold-weather operation
• Harness Reference: Kit #619900 available if harness is required
Applications: Designed for use with SKF / Haldex Turbo-2000 and HD-2000 air dryers on trucks, buses, trailers and military vehicles. This 24V heater kit helps prevent freezing in air brake systems by maintaining thermal control during cold-weather operation. Ideal for fleets operating in sub-zero conditions or military-grade chassis requiring plug-style heater kits.
CROSS-REFERENCE(S):
619111, FS-T619111SKF, 170.SKF619111, SC619111, PP619111, ST619111, FS-619111, 7-619111, TR-619111, TP-619111
A cross-reference listing means this part should be a suitable replacement for the part numbers listed. Please confirm all ports, wattage and voltage match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Disconnect power and fully depressurize the air system before starting installation.
✔ Confirm system voltage is 24V before replacing the heater to prevent burnout.
✔ Remove the old heater / thermostat assembly, clean the cavity and apply anti-seize compound where required.
✔ Align the plug connection correctly and secure the new unit using two 8-32 x 1/2" screws.
✔ Use with Metri-Pak connector; Kit #619900 is available if the harness is needed.
✔ To test, cool the thermostat to 35°F; continuity indicates correct operation.
✔ After installation, check for air leaks and confirm proper air dryer operation before returning the vehicle to service.
