109478PGX - MODEL IP COALESCING AIR DRYER (24V)
PART NUMBER(S):
Fleet Products: 109478PGX (New) | Replaces OE: Bendix 065613, 109478, K049690, K049691, K049692 | Haldex 65613 | International 2036838C91 | Mack 26QE434P10 | Meritor R955109478XCF, K109478RO, 800577 | Automann 170.065613
DESCRIPTION:
Model: Model IP Coalescing Air Dryer
Vehicles: Heavy-duty trucks, buses, and trailers equipped with Model IP air dryer systems and 24V electrical systems
• Voltage: 24V DC
• Supply Port: 1/2" NPT
• Delivery Port: 1/2" NPT
• Control Port: 1/4" NPT
• Cartridge Type: Coalescing Desiccant Cartridge
• Cartridge Thread: 1-1/4"-7 UNC-2B
• Purge Valve Type: Hard Seat
• Safety Valve Opening Pressure: 200 PSI
• Extended Purge Port: 1/8"-27 NPT (plugged)
• Minimum Operating Temperature: -40°F (-40°C)
• Mounting Style: Flange Mount
• Clearance Required for Cartridge Removal: 0.50"
• Bracket and Wiring Harness Not Included
Applications:
Designed for Model IP air dryer systems operating on 24V electrical systems. The integrated coalescing filtration removes moisture, oil aerosols, and solid contaminants from compressed air before they enter the air brake system. Ideal for heavy-duty truck, bus, and trailer applications requiring enhanced air quality and reliable cold-weather operation.
CROSS-REFERENCE(S):
109478X, 065613, 109478, 5003296, 65613, 801288, 109466, 109470, N065613, 109478RX, ZZ109478X, 170.065613, R955109478XCF, K109478RO, 800577, 2036838C91, 26QE434P10
A cross-reference listing means this part should be a suitable replacement for the part numbers listed. Please verify port configuration and electrical specifications before installation.
IMPORTANT INSTALLATION NOTES:
✔ Mounting bracket and wiring harness are not included and must be sourced separately if required.
✔ Verify vehicle electrical system is 24V before installation.
✔ Ensure supply, delivery, and control ports are connected to the correct locations.
✔ Allow a minimum of 0.50" clearance below the cartridge for future service and replacement.
✔ Fully depressurize the air system before servicing or replacing the dryer.
✔ After installation, test purge valve operation and inspect for air leaks.
