109477PGX - MODEL IP COALESCING DRYER - 12V
PART NUMBER(S):
Fleet Products: 109477PGX (Remanufactured) | Replaces OE: Haldex 65612, 109465, 109469, 109477, 109477PG, 109477X, 131038, 131066, 131080, 5000154, 5000155, 5000156, 5000794, 5001740, K026596 | Mack 26QE434P9, 745-109477X, 745065612, 74565612 | Meritor R955109477XCF, R955109477PGX, K109477RO, 800576 | Euclid EBN109477X, EBN109477XCF, R955109477X | International / Navistar 2036827C91, 2066827C91 | Automann 170.065612PG | Bendix 065612, 065612PG, 322-GN109477, BEN109477PGX | Newstar S-23097
DESCRIPTION:
Model: Model IP coalescing air dryer
Vehicles: Trucks and buses equipped with compatible Model IP air dryer systems
• Voltage: 12V DC
• Heater Wattage: 90W
• Supply Port: 1/2" NPT
• Delivery Port: 1/2" NPT
• Control Port: 1/4" NPT
• Cartridge Type: Coalescing filter
• Cartridge Thread: 1 1/4"-7 UNC-2B
• Purge Valve Type: Hard seat
• Safety Valve Opening: 200 PSI
• Mounting: Bracket not included
• Wiring Harness: Not included
• Desiccant: 100% new desiccant in remanufactured dryer
• Purge Valve Reference: New K022105-G3 purge valve installed on this dryer
Applications:
Designed for Model IP air dryer systems used on heavy-duty trucks and buses. This coalescing dryer removes moisture, oil aerosols, and contaminants from compressed air before it reaches reservoirs, valves, and brake components. Suitable for remanufactured dryer replacement where a 12V, 90W Model IP unit with coalescing filtration is required.
CROSS-REFERENCE(S):
109477PGX, BEN109477PGX, BW109477PGX, 109477PG, R955109477PGX, 170.065612, 170.065612PG, 65612, S-23097, 065612, 065612PG, 216560, 109477, 109477B1, 109477X, 2036827C91, 2066827C91, 26QE434P9, 745-109477X, 745065612, 74565612, BAR109477, BW 065612, BX109477B1, EBN109477X, EBN109477XCF, R955109477X, R955109477XCF, 061-109477X, TWDBEN065612, ZAC065612, 109465, 109469, 131038, 131066, 131080, 5000154, 5000155, 5000156, 5000794, 5001740, 800576, K109477RO, K026596, 322-GN109477 | Other BW109477PGX, 216560, 109477B1, BAR109477, BW 065612, BX109477B1, 061-109477X, TWDBEN065612, ZAC065612
A cross-reference listing means these part numbers are confirmed equivalents or replacements from manufacturers or distributors. Please confirm voltage, ports, mounting, and dryer configuration before installing.
IMPORTANT INSTALLATION NOTES:
✔ Core return required for remanufactured units.
✔ Fully depressurize the air system before servicing.
✔ Confirm 12V system voltage before installation.
✔ Follow OEM installation procedures for Model IP dryers.
✔ Bracket and wiring harness are not included; source separately if required.
✔ Confirm supply, delivery, and control port sizes before connecting air lines.
✔ After installation, check for air leaks and confirm proper purge operation.
