Description
102761-G - SR-2 TRAILER SPRING BRAKE VALVE WITH ANTI-COMPOUNDING
PART NUMBER(S):
Fleet Products: 102761-G | Replaces OE: Bendix: 102761 | Automann: 170.102761 | WABCO: 9738810010 | Mack: 745-102761 | Meritor: R955102761
DESCRIPTION:
Model: Bendix SR-2 Trailer Spring Brake Valve with Anti-Compounding
Vehicles: Heavy-duty trailers with compatible dual-circuit air brake systems
• Valve Type: SR-2 trailer spring brake valve
• Supply Port: One 1/4" NPT
• Trailer Service Port: One 1/4" NPT
• Delivery Ports: Four 3/8" NPT
• Reservoir Ports: Two 1/4" NPT, one 3/4" NPT
• Exhaust Port: One 3/8" NPT
• Mounting: 3/4" male NPT reservoir mount
• Closing Pressure: 70 PSI
• Operating Temperature: -50°F to 200°F (-45°C to 93°C)
• Charging Priority: Spring brake priority
• Anti-Compounding: Prevents combined spring and service brake forces
• Pressure-Loss Release: Allows one spring brake release after reservoir pressure loss
• Function: Controls trailer spring brake application and release
Applications:
Used in dual-circuit trailer air brake systems requiring spring brake priority and anti-compounding protection. The valve controls spring brake application and release, including a one-time release after reservoir pressure loss, while preventing service brake force from compounding with the spring brakes.
CROSS-REFERENCE(S):
102761N, 102761P, 102761RX, 102761X, OR102761, OR102761X, 170102761, S9738810010, 12900005, 401184, AV102761, BW102761, BX102761N, E-BN102761X, R955102761X, R9551102761N, TV102761, WA102761, K102761, K033216, S-A150, 8235R955102761X, R102761, R955102761XRI, TDAR955102761X
A cross-reference listing means this part may be a suitable replacement for the listed part numbers. Always verify fitment before installation.
IMPORTANT INSTALLATION NOTES:
✔ Mount directly to the trailer reservoir using the 3/4" male NPT connection.
✔ Confirm the supply, service, delivery, reservoir, and exhaust port routing before installation.
✔ Apply air-system-compatible thread sealant without allowing sealant to enter the valve.
✔ Pressurize the system and verify spring brake release, emergency application, and anti-compounding.
✔ Do not substitute an SR-1 valve without confirming the complete reservoir plumbing configuration.
