Product Description
FP790-92799WCX – AIR DISC CALIPER (DB22) WITH CARRIER (UNIVERSAL)
PART NUMBER(S):
Fleet Products: FP790-92799WCX (Remanufactured) | OE: Haldex # 91435, 93672, 92800, S-38177
DESCRIPTION:
Model: Haldex DB22 (Universal)
Vehicles: Heavy-duty trucks, buses, and trailers fitted with DB22 calipers Hendrickson axle
• Brake Side: Universal (LH/RH)
• Caliper Type: Air disc caliper with integrated carrier
• Mounting Style: Axial mount (Universal)
• Wheel Compatibility: 22.5"–24.5" wheels
• Brake Pad Compatibility: PE1527HK (193 cm² x 22 mm)
• Compatible Rotor: FP76810 (430 mm OD x 45 mm thick, 220 mm pilot)
• Recommended Pin Kit: FPK10194
• Compatible Spring Brakes: FPK132352
• Weight: ~39.9 kg (88 lbs)
• Brake Torque: ~22 kNm max clamp force
• Adjustability: Automatic pad adjustment, floating caliper with four guide pins
• Performance/Technology: Heavy-duty OEM-grade disc caliper for high GVW applications
• System Integrity: OEM-spec remanufactured
Applications:
The DB22 is engineered for Class 7–8 trucks and buses where maximum torque and braking power are required. Its robust pad area, larger carrier design, and higher torque rating (22 kNm) make it a direct-fit solution for demanding commercial fleets.
CROSS-REFERENCE(S):
91435, 92800, 93672, Haldex 790-94049, Haldex 94049, 94050, 94051, 94052, 070-79094049, 976100, 976100N, K022919, ModulX DB22 Universal ADB Caliper – Standard Bolt Pattern, 790-92799
A cross-reference listing means this part may be a compatible replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Ensure brake rotor spins freely before installation
✔ Use an 8 mm wrench on the adjuster shaft (55): rotate ¾ turn counter-clockwise to release adjustment
✔ Apply brakes five times—wrench must move each time, confirming auto-adjuster is working
✔ For clearance check: rotate clockwise until pads touch rotor, then back off ¼ turn
✔ Lubricate and refit the adjuster plug (15) with EP chassis grease (PN 89652 or equivalent)
✔ Never use impact wrenches on the adjuster mechanism
Application: DB22 - (Universal - Left or Right)
REMAN
SOLD AS REMANUFACTURED | CORE RETURN REQUIRED
Built to OEM standards | thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
