FP71-104 – 10" MAGNET KIT, ELECTRIC BRAKE ASSEMBLY REPLACEMENT
PART NUMBER(S):
Fleet Products: FP71-104 (New) | OE: 71-104, K71-104-00
DESCRIPTION:
Model: 10" Electric Brake Magnet Kit
Vehicles: Dexter, Lippert, AL-KO, and equivalent 3,500–5,200 lb axles with 10" electric brake assemblies
• Voltage: 12V DC electric brake magnet
• Wiring: 2-lead, non-polarized design for simple hookup
• Magnet Face: Standard round with flat contact surface
• Application: Replaces worn magnets in 10" electric brake assemblies
• Compatible Axles: 3,500–5,200 lb utility, RV, enclosed, cargo, horse, livestock, and boat trailers
Applications: Is this magnet right for your brake system✔ Yes—purpose-built for Dexter-style 10" electric brake assemblies on 3.5K–5.2K axles. Restores smooth braking, consistent magnet-to-drum engagement, and dependable stopping power across RV, utility, enclosed, and cargo trailers. Comes included with FP12-1013, FP12-1014
CROSS-REFERENCE(S):
K71-104-00, 007-102-00, 220-101, BP01-110, 296707, 363389.2, B10M-10, EMK-10, AKBRKR-M10, 160.7104, UTR007-102-00, UP220-101, FP-71-104, TSE-104, EZ-104, HB1004, QS104, UP104, TR-71-104, MD-104, TMK-104, PP-104, SC-104, FIP-104, B0C6KS3JHN, TB-104, SH-104, V-104, KB-104, PHD-104, 023-027-00, 160.24521A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Torque magnet hold-down bolts to 20–30 in-lbs
✔ Ensure magnet face sits flush and parallel with the armature plate
✔ Connect wiring to brake controller circuit (polarity not critical) with heat-resistant connectors
✔ Inspect for worn wires, grooved magnet faces, or reduced braking performance before reuse
✔ Set air gap clearance between magnet and drum to 0.015"–0.020" for optimal operation
