286535X - TF-501 Pulley Drive Compressor - Base Mount

(0) Write a Review
SKU:
286535X
Condition:
Refurbished
Availability:
Call 877-243-0442 for pricing. Mention code WEB1

Product Description

286535X - TF-501 BASE MOUNT COMPRESSOR (RIGHT PORTS, 6-HOLE)


PART NUMBER(S):
Fleet Products: 286535X (Remanufactured) | OE: 286529, 04625286592X, BXC286592X


DESCRIPTION:
Model: TF-501 Pulley Drive Air Brake Compressor – Base Mount
Vehicles: Bendix-based heavy-duty platforms, trucks, trailers
• Mounting Style: 6-Hole Base Mount
• Drive Type: Pulley (belt) driven
• Cooling: Water and Air cooled
• Air Inlet Port: Right (viewed from rear)
• Air Outlet Port: Right (viewed from rear)
• Discharge Type: Flange
• Bore: ~2.75" (70 mm)
• Stroke: ~1.5" (38 mm)
• Rated Displacement: ~12 CFM @ 1250 RPM
• Shaft/Spline: Standard pulley shaft (non-splined)
• Weight: Approx. 40 lbs

Applications:
Ideal for heavy trucks, trailers, and semi tractors requiring a TF-501 compressor with right-side ports and 6-hole base mount. Designed to provide reliable air pressure for braking and auxiliary systems in Bendix-compatible configurations.


CROSS-REFERENCE(S):
286535X, 286535, TF-501, 286529, 04625286592X, BXC286592X, 102822, 289751
A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.


IMPORTANT INSTALLATION NOTES:
✔ Confirm 6-hole base mount configuration matches original
✔ Torque flange bolts to 80–100 ft-lbs per OEM instructions
✔ Right inlet/outlet port alignment must match system layout
✔ Replace gaskets and follow TF-501 compressor install specs


SOLD AS REMANUFACTURED | CORE RETURN REQUIRED

Built to OEM standards | thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
