Description
RS451039 – 15' COIL AIR SET W/40" LEADS (11-3400)
PART NUMBER(S):
Fleet Products: RS451039 | OE: Phillips 11-3400, 11-5400, Automann 179.3003.15-40, 179.3003SWL.15-40
DESCRIPTION:
Model: RS451039 – 15' Coil Air Set with 40" Tractor Leads
Vehicles: Universal – extended wheelbase tractors and trailers requiring long reach leads
• Length: 15 ft overall with 40" tractor-side leads (12" trailer leads)
• Tubing: 1/2" OD reinforced nylon, DOT/SAE J844
• Fittings: 1/2" NPT brass, extended handles on Phillips versions
• Max Operating Pressure: 150 PSI
• Temp Range: -40°F to +200°F (Polar Air version -85°F to +195°F)
• Coil Memory: 4" Large coil diameter to prevent kinks
• Color-coded: Red (emergency), Blue (service)
• Weight: ~5 lbs
• Compliance: SAE J844, DOT FMVSS 571.106
Applications: Extended-lead air coil set designed for long wheelbase trucks, daycabs, and tractors pulling doubles or heavy trailers. Provides added clearance and leverage for easy coupling/uncoupling.
CROSS-REFERENCE(S):
Midwest WA451039N, Sirco A1040, Automann 179.3003.15-40, Velvac 022001, Tectran 17215-040, K1512RB40, 7100110, Euclid E-10746, Midland 11954, Phillips 11-3400, Sloan 451039N, Fleetcraft 1615040, Newstar S-21163, 11340, 17215040, PDC 11040, Grote 81-0015-40H, Grote 81001540H, 451042N, 17215-40H, 1721540H, 20093, 115400, 590160, ABP N42AAC15, RC AC15S, AC15S, WA451036N, PHI11315, NT11015S, 590160VELA cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm lead length and fitting type before installing.
IMPORTANT INSTALLATION NOTES:
✔ Tractor-side 40" leads provide additional clearance for extended wheelbase setups
✔ brass handles improve leverage and safety
✔ Install with proper coil support (spring kit or pogo stick)
✔ Meets SAE J844 and FMVSS requirements for highway safety
✔ Inspect regularly for wear, kinking, or sealant degradation
