RS451036 – 15' COIL AIR SET (11-5150)
PART NUMBER(S):
Fleet Products: RS451036 | OE: Phillips 11-315, 115150, Automann 179.3003.15, 179.3005CC.15
DESCRIPTION:
Model: RS451036 – 15' Coil Air Set
Vehicles: Universal fitment for tractors and trailers, DOT-approved for heavy-duty commercial use
• Length: 15 ft coiled air line set (service & emergency)
• Tubing: 1/2" OD reinforced nylon, SAE J844 Type B
• Fittings: 1/2" NPT brass with pre-applied sealant (fixed + swivel ends depending on spec)
• Max Operating Pressure: 150 PSI
• Temp Range: -40°F to +200°F (-40°C to +93°C)
• Coil Diameter: 4"
• Color-coded: Red (emergency) & Blue (service)
• Compliance: SAE J844, DOT FMVSS 571.106, 393.45
Applications: Standard-duty air coil set designed for tractors, trailers, and dollies. Provides OEM-level durability and flexibility in all weather. Trusted replacement for multiple OE assemblies across Phillips, Sloan, Haldex, Tectran, and more.
CROSS-REFERENCE(S):
Keene K1512RB, Sirco A1015, BWP M-499, Automann 179.3003.15, Midwest WA451036N, Velvac 022025, Tectran 17215, Sirco A1015, WA451036N, 7100100, Fleetcraft 1615012, Euclid E-10744, Midland 11952, Phillips 11-315, Sloan 451036N, Phillips 11315, 849811315, PDC 11015, RAT15N/ASOLD, R10744, R955, R10744RB, E10744, 3099157, 725284, 422552, 80910, 80956, 97620, 6564A, 421130A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm dimensions and fitting type before installing.
IMPORTANT INSTALLATION NOTES:
✔ Use with pogo stick or spring kit for coil support and tangle prevention
✔ Ensure fittings are torqued snug with thread sealant applied
✔ Red line = emergency, Blue line = service — always connect to correct gladhand port
✔ Regularly inspect coils for abrasion or kinking, replace as needed
✔ Meets all DOT and SAE standards for safe highway use
