Product Description
RC-01 – LUCAS INLINE RESIDUAL CHECK VALVE (5/16″ PORT)
PART NUMBER(S):
Fleet Products: RC-01 (New/Remanufactured) | OE: Lucas Girling RC-01, RRH01K
DESCRIPTION:
Model: Inline Residual Check Valve – 5/16″ Port (Lucas Girling Style)
Vehicles: Ford LN/FT-Series trucks, Freightliner medium-duty trucks, and commercial buses with Lucas Girling hydraulic brake systems
• Maintains 3–10 psi residual pressure in hydraulic brake systems to prevent seal leakage
• Inline installation between master cylinder and rear wheel-end “T” fitting
• Housing available in steel or brass with corrosion-resistant finish
• Supports service and parking brake hydraulic actuation in drum brake systems
Applications: Is this residual check valve right for your vehicle? Yes—engineered for Lucas Girling hydraulic systems in Ford, Freightliner, and bus applications. Keeps expander and adjuster cylinders sealed and operational by maintaining 10–14 psi in the circuit. Required for proper system function and warranty compliance on Lucas-style hydraulic drum brake assemblies.
Designed for use with Lucas Girling adjuster/expander cylinders (201179X, 201183X, 201180X, 201184X)
CROSS-REFERENCE(S):
RC-01, RC01, RC01X, RC-01X, RC01-LUCAS, RC-01LUCAS, RC-01-LUCAS, RC01-LUCASX, RC-01-LUCASX, RC01INLINE, RC-01INLINE, RRH01K, 650-RRH01K, RH01K, RH01KX, RH-01K, RH-01KX, BEPCO RC01, BEPCO RC-01, BEPCO RC01X, BEPCO RC-01X, 767653019230, 767653019231, 767653019232, TDA-RC01, TDA-RC-01, CE-RC01, CE-RC-01, MID-RC01, MID-RC-01, RH201183X-VALVE, RH201184X-VALVE, RH201180X-VALVE
A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Install inline between master cylinder and rear brake circuit “T” fitting
✔ Designed for Lucas Girling drum brake systems using adjuster/expander cylinders
✔ Maintains residual pressure (10–14 psi) to ensure seal integrity without brake drag
✔ Do not use DOT brake fluid – confirm correct hydraulic fluid type for your system
✔ Always verify flow direction during installation to prevent brake lock-up
✔ Replace valve if hydraulic leakage or pressure retention issues are detected
SOLD AS NEW
Brand New and ready to install , no core charges or reman processing required.
SUPPORT & ORDERING
For technical support, installation guidance, or to confirm fitment, Call: 1-877-243-0442 | Email: sales@fleet-products.com
