RA023 | 12V Solenoid Valve (5-Port, 2-Pos, 1/4" NPT)

RA023 SOLENOID VALVE 12V, 5 PORT, 2 POS

PART NUMBER(S):
Fleet Products: RA023 | OE: RA023 | Automann: 173.V34203

DESCRIPTION:

Model: 5-Port, 2-Position Solenoid Valve
Vehicles: Compatible with truck and trailer systems requiring air actuation for lift axle or double-acting cylinder control
• Valve Type: 5-port, 2-position (5/2) configuration
• Port Size: 1/4" NPT (all ports)
• Actuation: Solenoid-operated (12V DC), spring return
• Electrical: 12V DC coil, compatible with heavy-duty vehicle wiring
• Operating Pressure Range: 50–150 PSI
• Airflow: Estimated ~50 SCFM
• Mounting: Inline or panel mounting (hardware not included)
• System Type: For use in double-acting cylinder control (e.g., raise/lower lift axle)
• Construction: Corrosion-resistant composite or aluminum body
• Function: Directs pressurized air to cylinder ends; spring return ensures default position
• Compatibility: Replaces Automann 173.V34203, AIRman V2506R0514-DAL-BLK

Applications:
Designed for control of double-acting cylinders in truck and trailer applications such as lift axle deployment or suspension actuation. Provides fail-safe spring return when de-energized, ensuring predictable air circuit behavior in the event of power loss.

CROSS-REFERENCE(S):

A cross-reference listing means this part may be a compatible replacement for these part numbers based on OEM or distributor data.

IMPORTANT INSTALLATION NOTES:
✔ Use 1/4" NPT fittings on all five ports for proper sealing
✔ Confirm power supply is 12V DC before installation
✔ Spring return action requires no manual reset—test function prior to service
✔ Ensure valve is mounted in an accessible location for wiring and maintenance
✔ Avoid over-tightening port fittings to prevent thread damage
