EL365007X MIDLAND "CERTIFIED REMANUFACTURED" AIR BRAKE COMPRESSOR – CAT C7 & C9 ENGINE – 2-BOLT FLANGE
PART NUMBER(S):
Fleet Products: KN365007X (Remanufactured) | OE: CAT: 273-6053, 276-0806, 311-4562, 273-6051, 10R-5296, 10R-9391, 296-7668, 314-6149, 344-6362, 304-9982 | MIDLAND: N7212FM
DESCRIPTION:
Model: Midland EL365 Style 2-Bolt Flange Mount
Vehicles: Caterpillar C7 & C9 Diesel Engines (2004–2010)
• 11-tooth spline gear with 2-bolt flange mounting
• 16.1 CFM airflow capacity
• Flow Capacity: 10.5 CFM @ 1800 RPM and 125 PSI
• Swept Volume: 365CC
• Piston Diameter: 2.75 in
• Stroke: 1.87 in
• Loaded HP: 4.5 HP | Unloaded HP: 1.4 HP
• Twin-cylinder design for reduced vibration and pulsation
• Rear head configuration with right-hand rotation
• Check valve pre-installed
• Water-cooled block and head
• Drive-thru torque capacity: 150 ft-lb (203.4 Nm)
• Maximum RPM: 3000
• Inlet Pressure: Naturally aspirated to 60 PSI (turbo compatible)
• Exhaust Pressure: 8.6 bar (125 PSI)
• Oil Temp: 99°C (210°F) @ 2.4 bar (35 PSI)
• Coolant Temp: 88°C (190°F) @ 0.83 bar (12 PSI)
• Ambient Inlet Temp: 30–32°C (86–89.6°F)
• Accessory mounting flange: SAE “A” 2-bolt
• Includes pressure relief valve and installation gaskets
• Supplied without governor and manifolds
Applications:
Used on Caterpillar C7 and C9 engine platforms in medium- and heavy-duty trucks, vocational vehicles, and construction equipment. This EL365 compressor provides consistent high air output for demanding air brake systems and supports accessory drive-through applications such as hydraulic or steering pumps.
CROSS-REFERENCE(S):
10R9391, 5396-EL365007X, N7212FM, EL365007X, N7212AS, N7212CB, N7212EH, N7212FF, 10R5296, 296-7668, 314-6149, 344-6362, 2967668, 3146149, 3446362, 273-6053, 276-0806, 311-4562, 273-6051, 10R5296, 10R-5296, 10R9391, 10R-9391, 296-7668, 2967668, 314-6149, 3146149, 344-6362, 3446362, 304-9982
A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Use clean, filtered engine oil (≤40 micron); maintain proper oil pressure and temperature to prevent wear
✔ Ensure coolant flow (min. 2.5 GPM) with correct routing; do not exceed 266°F (130°C)
✔ Maintain proper oil drain through mounting flange; do not block passages or use sealants
✔ Keep intake restriction below 20" HO and use high-efficiency air filtration
✔ Use correct discharge line size (min. 0.547" ID) and route downward to avoid buildup
✔ Do not exceed 190 PSI discharge pressure or 3000 RPM operation
✔ Maintain proper tilt limits to ensure lubrication (max 30° rotation, 10° static tilt)
✔ Use minimum 1/4" ID governor line; keep short and unrestricted to avoid pressure fluctuation
SOLD AS REMANUFACTURED – CORE RETURN REQUIRED
Built to OEM standards — thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
