Product Description
KN13050X - EL1300 DETROIT COMPRESSOR
PART NUMBER(S):
Fleet Products: KN13050X (Remanufactured) | OE: KN13050, EL13050, EL13050X, N7005H, KN7070X, KN7080X (must rotate head for KN7080X and N7005H), Navistar (468579C91, 476522C91, 866781R91, 990419C91, 994866C91)
DESCRIPTION:
Model: EL1300 Detroit Compressor (Reman: KN13050X)
Vehicles: Detroit Diesel DDC 0° Tilt Engines
• Cooling: Water cooled
• Air Inlet Location: Top
• Air Outlet Location: Flange Discharge Type
• Mounting Type: Flange Mount, Double Flange, 4-holed
• Drive: Gear Drive
• Oil Feed/Drain: End Cap Oil Feed, Oil Drain Internal at Flange
• Turbo Support: Turbochangeable
• Head Rotation: Right (Rotatable, must rotate for certain legacy numbers)
• Block Rotation: Right
• Bore Diameter: 2.75 in.
• Stroke: 1.50 in.
• Rated Displacement: 13.0 CFM @ 1250 RPM
• Approximate Weight: 50 lbs
• Substitution: Substitutes for KN7070X and KN7080X; must rotate head for KN7080X
Applications:
The EL1300 Detroit Compressor (KN13050X) is used for Detroit Diesel DDC 0° Tilt engines within heavy trucks, semi trucks, 18 wheelers, and commercial vehicles. It is used to pressurize air for the actuation of air brakes and features gear drive with flange mount.
CROSS-REFERENCE(S):
KN13050, EL13050, EL1300, KN13050A, KN13050N, KN13050T, BAREL13050X, BXEL13050X, EMDEL13050X, N7005AD, N7005AG, N7005D, N7005F, N7005H, N7005M, N7005R, N7006N, T7005AD, R955286539X, R955286581X, R955EL13050X, EL13050, KN7070X, KN7080X, N7005H, R955EL13050X, R955KN7070X, N7005H, KN7070X. KN7080X (must rotate head for KN7080X and N7005H), 468579C91, 476522C91, 866781R91, 990419C91, 994866C91, R955EL13050X, BEPCO EL13050X, GK13050, N7005A, 101143, SF59337, 275007, G2008787, 276961N, E-MDEL13050X, Midland 276961X, Bendix 101143, AM General SF59337, GMC 15505543, Ford E0HT2875CA, Mack 101268, Detroit Diesel 23500452, Pierce Mfg Inc 1708888, Volvo GM Heavy Truck G2008787, NAPA 276961N, EUCLID E-MDEL13050X, MIDLAND 276961X, Midland EL13050, Midland EL13050X, 2429194, 15505543, 15509065, 15509072, 2437362, 15527474, 15534965, 2445216, 2453811, 226499, 226695, 226862, 227325, 227329, 227330, 227928, 2279284, 228058, 228332, 228333, 228334, 228335, 228336, 228337, 228338, 228421, 228446, 228879, 228880, 229222, 228301, 1143, 226288, 226438, 227140, 227579, 228373, 229563, 229694, 229695, 400668C91, 400668C92, 400676C91, 400677C91, 275007, 275231, 275857, 276111, 276167, 276843, 276915, 276961, 276961N, 276961X, 276962, 277463, 277686, 279045, 279067, 279068, 279069, 279312, 27961X, 279662, 279921, 306376C91, 23500452, 23500453, 280095, 408424C91, 280963, 280964, 280989, 409908C91, 281661, 281730, 281733, 281885, 282012, 282094, 282261, 2193353, 282382, 283048, 283299, 283339, 283424, 283458, 283459, 283461, 283462, 283468, 283495, 283950, 284055, 284078, 284265, 284266, 284269, 284288, 284682, 284693, 284696, 284698, 285359, 285590, 285950, 285984, 229470, 275039, 2011455, 277241, 277242, 277645, 279008, 279009, 2333493, 2338950, 2028778, 280365, 280368, 281043, 282389, 282395, 282396, 282397, 282398, 282626, 282745, 283515, 285866, 285970, 285971, 285972,
A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Head is rotatable; may require rotation on install
✔ Includes installation gaskets
✔ All port orientations are viewed from the front
✔ Substitute for KN7070X and KN7080X (Head roation required)
SOLD AS REMANUFACTURED | CORE RETURN REQUIRED
Built to OEM standards | thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
