Product Description
FP40175091X – AIR DISC CALIPER (PAN 17) (RH, WITHOUT CARRIER)
PART NUMBER(S):
Fleet Products: FP40175091X (Reman) | OE: WABCO 40175091, Hendrickson D-34766-R, Meritor S40175091, Automann 158.40175073
DESCRIPTION:
Model: WABCO PAN17
Vehicles: IMT Trailer Axles (PAN17 Caliper, Right-Hand)
• Brake Side: Right-Hand (RH)
• Caliper Type: Air disc caliper, supplied without carrier
• Carrier Fitment: Compatible with IMT RH carrier FP30187
• Brake Disc Thickness: 34 mm
• Rotor Diameter: 330 mm
• Stroke: 21 mm
• Mounting Style: Bolt-on (4x M12 x 1.5 bolts)
• Housing Dimensions: 305 x 355 x 182 mm
• Weight: 23.6 kg (51.9 lbs)
• Piston: Twin 50 mm pistons
• Brake Pad Compatibility: PE1518HK
• Compatible Rotor: FP75180 (U-style PAN17, 325 mm OD)
• Recommended Pin Kit: FPK30143
• Compatible Spring Brakes: FPK041960
• Carrier: IMT RH (FP30187)
Applications: Is this caliper right for your trailer? Yes—this RH WABCO PAN17 caliper (without carrier) is engineered for IMT trailer axles. Carrier FP30187 must be installed for proper alignment. Suitable for Hendrickson IMT trailers (HIMTR, HIMTS, HIMTT) and OEM trailer brands including Utility (4000D, 4000T, 4000X), Great Dane (Everest, Evergreen), and Wabash (DuraPlate, DuraPlate HD).
CROSS-REFERENCE(S):
40175091, 40175073, 40175090, 40175073NX, 40175073X, M40175073X, 650-40175091, 650-40175073, 1660463, S39094R, S-39094-R, BADC06R, BADC06R-G, GBADC5091, PN17W175072R, FP40175073WCX, FP40175073WC-G, RAD40175073X, 15840175073, 15840175073-G, Meritor 40-175-073, Meritor 40175073, Dayton 40175073, Wabco 40175079, X8827801, 500328233, 445332036, 5001852883, 5010422261, 1403633, 1440501, 12999807, S-33649-8, 1522094, 1522112, 6401751300
A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Use only on IMT trailer axles with PAN17 RH configuration.
✔ Carrier FP30187 is required for correct mounting and alignment.
✔ Replace LH and RH calipers as a set for balanced braking.
✔ Clean and prep mounting surfaces; torque bolts to OEM specifications.
✔ Adjust clearance: turn counter-clockwise until pads contact rotor, then clockwise 1/4 turn.
✔ Confirm system air pressure is 100–120 psi before operation.
SOLD AS REMANUFACTURED | CORE RETURN REQUIRED
Built to OEM standards | thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
