Product Description
FP30197 AIR DISC CARRIER – PAN22 (RH) (HENDRICKSON AXLE, WABCO)
PART NUMBER(S):
Fleet Products: FP30197
OE: 30197, 6402259362
DESCRIPTION:
Model: Wabco PAN22 (RH) Disc Brake Carrier
Engines: N/A
Vehicles: Hendrickson INTRAAX, VANTRAAX, ULTRAA-K, TRLAXLE trailer axles equipped with Wabco PAN22 calipers
• Side: Right-Hand (RH) orientation for PAN22 on Hendrickson axles
• Mounting: Axial mount, standard for PAN22 on Hendrickson axle
• Rotor Compatibility: 430 mm OD (16.93"), 45 mm thickness (new), fits 22.5"/24.5" wheels
• Material: Ductile iron carrier with corrosion-resistant finish
• ABS Integration: Rotor-mounted tone ring, compatible with RSS/ECBS systems
• Weight: 9.28 kg (20.5 lbs) for carrier only
• Caliper Fitment: FP40225016WC-G, FP40225016WCX, FP6402250810WC-G, FP6402250810WCX
Applications:
Carrier assembly for Wabco PAN22 right-hand caliper on Hendrickson trailer axles. Provides robust mounting interface for disc brake rotor, ensuring proper alignment and ABS tone-ring integration. Ideal for heavy-duty trailer braking on Hendrickson suspensions.
CROSS-REFERENCE(S):
30197, 6402259362, RAD30197, 0810 30197
A cross-reference listing means this item is functionally compatible with the listed part numbers but may differ by brand or source.
IMPORTANT INSTALLATION NOTES:
✔ Use exclusively on right-hand side of Hendrickson axles with PAN22 disc brake systems.
✔ Mount carrier using OEM hardware; torque fasteners to manufacturer specifications.
✔ Verify rotor compatibility (430 mm OD, 45 mm thickness) before assembly.
✔ Ensure ABS tone ring is seated correctly and aligned with sensor.
✔ Replace both LH and RH carriers/calipers simultaneously for balanced braking performance.
✔ Inspect rotor mounting surface and hub splines for damage or corrosion prior to installation.
SOLD AS NEW
Brand new and ready to install, with OEM Grade Reliability
SUPPORT & ORDERING
For technical support, installation guidance, or to confirm fitment, Call: 1-877-243-0442 | Email: sales@fleet-products.com
