Product Description
286542X - TF-501 DETROIT COMPRESSOR (45° TILT, ENGINE DRIVE)
PART NUMBER(S):
Fleet Products: 286542X (Remanufactured) | OE: 286541, 106290, 286623
DESCRIPTION:
Model: TF-501 Detroit Compressor
Vehicles: Detroit Diesel engine platforms with 45° flange tilt
• Cooling: Water/Air
• Air Inlet Location: Left
• Air Outlet Location: Top
• Discharge Type: Threaded
• Mount Type: Flange Mount (Engine Driven)
• Shaft Style: Spline
• Tilt Angle: 45°
• Approximate Weight: 45 lbs
• Features: Left-top port orientation, spline flange, horizontal mount
• Includes: Installation gaskets
• Notes: EL13160X compressors may also be used for this application
Applications:
Used in Detroit Diesel-powered heavy trucks requiring a TF-501 compressor with 45° tilted engine-mounted flange. Ideal for air brake system pressurization on vehicles with top discharge and left-side air inlet configuration.
CROSS-REFERENCE(S):
04625286623X, 101558K, 106290, 106290X, 109866, 126541, 279615K, 286538, 286541, 286542, 286619, 286623, 286623X, 286542X-BW, 286568, 287641, 287792, 287793, 3131755, 467418C91, 476523C91, 480446C91, 480951C91, 745-286542X, 990418C91, BEN286623X, BEN286542X, BX286623X, BX286542X, E1HT2875JB, E2HT2875AA, E3HT2875EB, EBN286542X, EOHT2875N2A, EL13160, EL13160X, KN13090, KN13100, KNX13090, KNX13100, KNX13160, N7009C, N7009D, N7009E, N7009F, N7009G, N7010A, N7010B, N7010C, N7010D, N7010E, N7010F, N7010N, R955286542X
A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.
IMPORTANT INSTALLATION NOTES:
✔ Port orientation is always viewed from the rear
✔ Designed for engine-driven applications with 45° tilted flange mount
✔ Includes installation gaskets; verify proper alignment and torque to OEM spec
✔ EL13160 and EL13160X may be used as alternates in matching fitments
✔ Ensure top discharge and left-side air inlet compatibility before installation
PICTURE USED FOR WEBSITE PURPOSE ONLY
SOLD AS REMANUFACTURED | CORE RETURN REQUIRED
Built to OEM standards | thoroughly cleaned, inspected, and tested to ensure durability, performance, and reliability in demanding applications.
