065225-G | Model 9 Air Dryer (12V, 75W) W/Bracket & Plug (109685) 5009378

065225-G – MODEL 9 COALESCING DRYER (12V) WITH BRACKET & WIRE HARNESS

PART NUMBER(S):
Fleet Products: 065225-G (New) | OE: Bendix 109685, Volvo 1091606, Mack 26QE377, 4006110500

• Model 9 air dryer – testing procedure
• Model 9 air dryer – service bulletin

DESCRIPTION:
Model: Haldex Model 9 Coalescing Dryer
Engines: All air brake-equipped diesel engines
Vehicles: Kenworth, Freightliner, Mack, International, Peterbilt, Volvo (Trucks, Tractors, Buses)

• 12V heater, 75W
• 1/2" NPT supply & delivery ports
• 1/4" NPT control port
• Mounting Style: Bracket included

Applications:
Is this air dryer compatible with your Model system? Yes — built as a direct-fit upgrade for Model 9 units, this Model 9 coalescing dryer delivers clean, moisture-free, oil-free air. Designed for heavy fleets running in extreme climates, it protects valves, chambers, and ABS components by removing fine oil aerosols before they enter the brake system.

CROSS-REFERENCE(S):

065225-G, 065225, 65225, 065225G, 109685, 109685X, F224680, 26QE377, 065225BXW, 109685BXR, 5009378BXR, R955065225XRMAN, 107695K, V1091606, V1092441, 20991976, 71301-0061, 71301-0062, 745065225, BX065225, ZAC065225, F0HZ2A131A, 4317715, TR065225, ETP-065225, FP-065225, GN065225PTP, TP-065225, ST-065225, PHD-065225, VIP-065225, 800202, 65226, 065226, 065226BXR, 065226BXW, 107953, 109688X, 1673737C91, 2072029, 26QE377P4, 26QE377P5, 26QE377P6, 2FS82, 3615614C91, 5017281, 6814310115, 6814310315, 745-065225, 745-109685, 745-65225, 745-O65225, 800202BXW, 9002783, 917352, AD2001, AT065225, AT065225K, AT065225KTEC, AV065225, BAN065225, BBH109685R, BW065225, BW065226, BW109685X, CR065225, ETP065225, EX109685X, HDX109685X, HDX109685XX, K065225, LAD5586, MERR955205, PD65225P, R955065225N, R955065225XCF, S-F345, SAP65225D, SF345, TECAT065225K, TWDBEN065225, WA9922007, WAP22-007, WAP22-009, R955109685HX, R955109689X, 65041X, 4008507010, 65226 R955065225X DA34100, 4006110500, 400 611 050 0

A cross-reference listing means this part is a suitable replacement for the part numbers listed. Please confirm all ports and dimensions match your application before installing.

IMPORTANT INSTALLATION NOTES:
✔ Always depressurize the air system before service
✔ Mount using supplied bracket and Model 9 bolt pattern
✔ Use thread sealant or Teflon tape for airtight sealing
✔ Verify “PG” coalescing label before installation (oil-filtration version)
✔ Check heater connector is fully seated after install
